No.
Descriptions
Values
Unit
Supplier
434 MHz
+20 dBm
868 /915 MHz
+20 dBm
L2
±5%, 0402 Multilayer chip inductor
27
6.8
nH
Sunlord SDCL
L3
±5%, 0402 Multilayer chip inductor
18
12
nH
Sunlord SDCL
L4
±5%, 0402 Multilayer chip inductor
33
22
nH
Sunlord SDCL
L5
±5%, 0402 Multilayer chip inductor
15
10
nH
Sunlord SDCL
L6
±5%, 0402 Multilayer chip inductor
27
12
nH
Sunlord SDCL
L7
±5%, 0402 Multilayer chip inductor
27
12
nH
Sunlord SDCL
L8
±5%, 0402 Multilayer chip inductor
68
18
nH
Sunlord SDCL
Y1
±10 ppm, SMD32*25 mm
26
MHz
EPSON
U1
CMT2300A, Ultra Low Power Sub-1GHz RF
Transceiver
-
-
CMOSTEK
U2
AS179, PHEMT GaAs IC SPDT Switch
-
-
SKYWORKS
R1
±5%, 0402
2.2
kΩ
R2
±5%, 0402
2.2
kΩ
