CMOSTEK CMT2310A - Electrical Specifications; Recommended Operating Conditions; Absolute Maximum Ratings

CMT2310A
Rev 1.0E | Page4/50
www.cmostek.com
1 Electrical Specifications
The measurement conditions are: V
DD
= 3.3 V ， T
OP
= 25 °C ， F
RF
= 433.92 MHz, sensitivity is measured by receiving a PN9
sequence, matching to 50 Ω impedance and 0.1% BER if nothing else stated. All measurement results are obtained using the
evaluation board CMT2310A-EM if nothing else stated.
1.1 Recommended Operating Conditions
Table 1. Recommended Operating Conditions
Parameter
Symbol
Condition
Min.
Typ.
Max.
Unit
Operating supply voltage
V
DD
1.8
3.6
V
Operating temperature
T
OP
-40
85
℃
Supply voltage slope
1
mV/us
1.2 Absolute Maximum Ratings
Table 2. Absolute Maximum Ratings
[1]
Parameter
Symbol
Condition
Min.
Typ.
Max.
Supply voltage
V
DD
-0.3
3.6
V
Interface voltage
V
IN
-0.3
3.6
V
Junction temperature
T
J
-40
125
℃
Storage temperature
T
STG
-50
150
℃
Soldering temperature
T
SDR
Last for at least 30 seconds
Human body model (HBM)
255
℃
ESD rating
[2]
Human body model (HBM)
-2
2
kV
Latch-up current
@ 85 ℃
-100
100
mA
Notes:
[1]. Exceeding the Absolute Maximum Ratings may cause permanent damage to the equipment. This value is a pressure
rating and does not imply that the function of the equipment is affected under this pressure condition, but if it is exposed to
absolute maximum ratings for extended periods of time, it may affect equipment reliability.
[2]. The CMT2310A is a high performance RF integrated circuit. The operation and assembly of this chip should only be
performed on a workbench with good ESD protection.
Caution! ESD sensitive device.Precaution should be used when handling the device in order to
prevent performance degradation or loss of functionality.
