11 Top Marking
Figure 34. CMT2310A Top Marking
Table 24. CMT2310ATop Marking Information
Marking method
Laser.
Pin 1 mark
Diameter of the circle = 0.3 mm.
Font size
0.5 mm, align right.
Line 1 marking
2310A, refers to model CMT2310A.
Line 2 marking
①②③④ is internal tracing code.
Line 3 marking
YWW is the date code is assigned by assembly factory. Y represents the last digit of the year.
WW represents working week.
