Section 4 Maintenance & Service
CAUTION
Follow the directions for use and handling of muriatic
acid on the acid bottle label, being careful to protect your eyes, wear
rubber gloves, and avoid breathing acid fumes.
NOTE: DO NOT USE ABRASIVE CLEANERS as they can scratch
the high quality quartz glass. If lime or hardwater calcium deposits
are encountered, use household tub and shower lime removal. After
cleaning the Quartz Tube, wash it o and wipe dry. Inspect the Quartz
Tube for cracks. Replace if cracks are found. Make sure the inside of
the Quartz Tube is dry before replacing the UV Lamp(s).
NOTE: DAMAGES CAUSED BY BROKEN QUARTZ TUBES ARE NOT
COVERED UNDER YOUR LIMITED WARRANTY.
4D-3QuartzTubeInstallation
1. While holding the Quartz Tube so it is oriented straight up and
down, insert the Quartz Tube into the UV Reactor until it is fully
seated in the bottom of the UV Reactor.
Note: If the end of the Quartz Tube is protruding from the UV
Reactor, the alignment is o. Remove and re-insert the Quartz
Tube to seat it properly as shown in Figure 8.
2. Place a Sealing O-Ring approximately 1/2in (12.7mm) from the end
of the Quartz Tube protruding from the top of the UV Reactor.
3. Place the Lamp Retainer over the Quartz Tube and using the hex
key included in the parts bag, attach the Lamp Retainer to the UV
Reactor using the Lamp Retainer Screws and Washers as shown
in Figure 7. Make sure the Lamp Retainer anges are fully seated
against the UV Reactor.
4. Turn the circulation pump ON and check the Quartz Tube seal for
leaks.
5. Turn the circulation pump OFF once you have conrmed that the
Quartz Tube is not leaking.
