CMP DEL AOP 50 - 4 B. System Maintenance; 4 C. Ozone Module Servicing

9
Section 4 Maintenance & Service
4B. SystemMaintenance
Use a size 2 phillips driver to remove the UV Access Panel or a at tool
to open the Enclosure Cover as needed.
NOTE: The DEL AOP 50 will not operate until the UV access panel is
replaced.
4B-1.OzoneModuleMaintenance
The green Ozone Module Lights on the Ozone Modules indicate that
the Ozone Power Supply is operating properly. When an indicator
light goes out, replace the corresponding Ozone Module.
4B-2.OzoneModuleReplacementInterval
Ozone module life expectancy is 5 years. Even if the Ozone Module
Light(s) are glowing, the Ozone Module may be producing little or
no ozone after this period of time due to contamination within the
corona discharge ozone chamber.
4B-3.OzoneGasLineReplacementInterval
Replace the Ozone Gas Line every year or sooner, if needed. If there is
evidence of water leaking past the Ozone Check Valve toward the Ozone
Modules, shut down the DEL AOP 50 immediately and replace the Ozone
Gas Line. If water entered the Ozone Modules, run the ltration system
so air will be drawn through the Ozone Modules and they can dry out.
Ozone Modules will return to normal operation when dry.
WARNING
Trace amounts of nitric acid may be present in the
Ozone Gas Line. Wear proper safety equipment (gloves and eye
protection) and avoid direct contact with any condensation in the line.
4C. OzoneModuleServicing-RefertoFigure 5
4C-1. Opening the Door
The DEL AOP 50 may be serviced without disconnecting any of the
plumbing or wiring. Simply use a slotted screwdriver to turn the door
latches a half turn counter clockwise and open the door. Reverse the
steps to securely close the door.
