PWM3 lower bit of duty register PWMD3L (1AH)
1AH
Bit7
Bit6
Bit5
Bit4
Bit3
Bit2
Bit1
Bit0
PWMD3L
PWMD3[7:0]
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Reset value
0
0
0
0
0
0
0
0
Bit7~Bit0
PWMD3[7:0]:
PWM3 lower bit of duty register.
PWM4 lower bit of duty register PWMD4L (1BH)
1BH
Bit7
Bit6
Bit5
Bit4
Bit3
Bit2
Bit1
Bit0
PWMD4L
PWMD4[7:0]
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Reset value
0
0
0
0
0
0
0
0
Bit7~Bit0
PWMD4[7:0]:
PWM4 lower bit of duty register.
PWM0/PWM1 higher bit of duty register PWMD01H (1CH)
1CH
Bit7
Bit6
Bit5
Bit4
Bit3
Bit2
Bit1
Bit0
PWMD01H
---
---
PWMD1[9:8]
---
---
PWMD0[9:8]
R/W
---
---
R/W
---
---
----
R/W
R/W
Reset value
---
---
0
---
---
----
0
0
Bit7~Bit6
Not used.
Bit5~Bit4
PWMD1[9:8]:
PWM1 higher 2 bits of duty register.
Bit3~Bit2
Not used.
Bit1~Bit0
PWMD0[9:8]:
PWM0 higher 2 bits of duty register.
Note:
Writing to PWMD1[9:8] does not take effect immediately, it takes effect after writing to PWMD1L.
Writing to PWMD0[9:8] does not take effect immediately, it takes effect after writing to PWMD0L.
PWM2/PWM3 higher bit of duty register PWMD23H (0EH)
0EH
Bit7
Bit6
Bit5
Bit4
Bit3
Bit2
Bit1
Bit0
PWMD23H
---
---
PWMD3[9:8]
---
---
PWMD2[9:8]
R/W
---
---
R/W
---
---
----
R/W
R/W
Reset value
---
---
0
---
---
----
0
0
Bit7~Bit6
Not used.
Bit5~Bit4
PWMD3[9:8]:
PWM3 higher 2 bits of duty register.
Bit3~Bit2
Not used.
Bit1~Bit0
PWMD2[9:8]:
PWM2 higher 2 bits of duty register.
Note:
Writing to PWMD3[9:8] does not take effect immediately, it takes effect after writing to
PWMD3L.Writing to PWMD2[9:8] does not take effect immediately, it takes effect after writing to
PWMD2L.
