PWM0/PWM1 dead-time register PWM01DT (0FH)
0FH
Bit7
Bit6
Bit5
Bit4
Bit3
Bit2
Bit1
Bit0
PWM01DT
---
---
PWM01DT[5:0]
R/W
---
---
R/W
R/W
R/W
R/W
R/W
R/W
Reset value
---
---
0
0
0
0
0
0
Bit7~Bit6
Not used.
Bit5~Bit0
PWM01DT[5:0]:
PWM0/PWM1 dead-time register.
PWM2/PWM3 dead-time register PWM23DT (10H)
10H
Bit7
Bit6
Bit5
Bit4
Bit3
Bit2
Bit1
Bit0
PWM23DT
---
---
PWM23DT[5:0]
R/W
---
---
R/W
R/W
R/W
R/W
R/W
R/W
Reset value
---
---
0
0
0
0
0
0
Bit7~Bit6
Not used.
Bit5~Bit0
PWM23DT[5:0]:
PWM2/PWM3 dead-time register.
