9
Note: The screw M4*30mm here requires a 3mm hexagon wrench. When connecting the spindle motor cable,
observe the direction of spindle rotation and turn clockwise to indicate that the connection is correct.
Otherwise, change the connection position.
Step7 Control Board Installation
Note: only need to fix the screws in the upper row

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the CNC 3018-PRO and is the answer not in the manual?

CNC 3018-PRO Specifications

General IconGeneral
ModelCNC 3018-PRO
Working Area300 x 180 x 45 mm
Frame MaterialAluminum
Control SoftwareGRBL
Power Supply24V 5.6A
InterfaceUSB
Machine Size400 x 330 x 240 mm
Spindle Motor775 spindle motor (12-36V) 24V:10000rpm
Supported OSWindows XP/7/8/10, Linux
Supported File FormatsG-code, nc, ncc, tap
Stepper Motor1.3A, 12V, 0.25Nm
