Cutting with the blade

at an angle of 0° - 45°

Youcancutatanangleof0°-45°withthissaw.

1. Loosenthelockinglever(13)afterwhich

thebladecanbeleanedinthedesired

anglewiththehelpofthescale(15).

2. Pullthelockinglever(13)tight.

3. Cutaccordingtothedirectionsabove.

Fine-tuning of the 0° and 45° angles

1. Loosenthelockinglever(13)andangleto

sawtowardsposition0°.

2. Verifytheanglebetweenthebladeandthe

sawtablewitha90°angleguide.

3. Ifneeded,adjustthebottompositionwiththe

adjustmentscrew(24)bylooseningthenut

andadjustingthescrew,xthescrewafter

theadjustmentbytighteningthenutagain.

4. Whenadjustingthe45°bottomposition,



doasdescribedabove,however,adjust

withadjustmentscrew(25)andusea45°

angleguide.
