CO/Tech J1x-JF2-210 - Mitre Sawing Angles; Setting Mitre Angles (-45°;0°;+45°)

15
ENGLISH
4
26
12
10
Mitre sawing - 45° / 0° / + 45°
Youcanmitresawwiththissawatanangleof-45°/0°/+45°.
1. Releasethesawhead(4)toitsupperpositionbyremovingthestop(16).
2. Releasethelockingwheel(10).
3. Pressthestop(26)andadjusttothedesiredmitreanglebyusingthescale(12).
4. Tightenthelockingwheel(10)andcutaccordingtothedirectionsabove.
