18
ENGLISH
18
Min.length6mm
Inspection and replacement of carbon brushes
Caution:
Unplugthepowercordbeforeinspectingthecarbonbrushes.
Thelifeexpectancyofthecarbonbrushesvariesdependingontheusageof

themotor.Checkthemafter50machinehoursifthesawisneworifyouhave
replacedthebrushes.Aftertherstinspection,checkthemaftereverytenth
machinehouruntilitistimefornewbrushes.
Check the brushes in the following manner
1. Removethetwolids(18),oneoneachsideofthemotor.
2. Thecarbonbrushesareplacedinsidethelids,pulloutthecarbonbrushes.
3. Checkthelengthofthebrushes(atleast6mm).
4. Replacebothcarbonbrushesifeitheroneisbelow6mmorifanyspringor
shuntthreadisburntordamagedinanyway.
