Carburettor settings
The carburettor has been factory adjusted for optimum power.
Storage
• The fuel tank and carburettor should not be left filled with petrol over thewinter, as this could lead to
startingproblems.
• Empty thefuel tank by starting theengine and letting it run until it is out offuel.
• Clean thetrimmer before putting it away for storage.
• Fit theblade guard onto thebrush cutter blade.
• Store thetrimmer in adry, dust-free environment out of thereach of children.
Troubleshooting guide
Problem Cause
The engine won’t start or
only runs at lowspeed.
• Incorrect starting procedure. Readtheinstruction manual.
• Faulty spark plug. Cleanor change thesparkplug.
• Dirt in thecarburettor. Getaqualified technician to clean thecarburettor.
• Clogged fuel filter. Changethefuel filter (inside thefuel tank).
The engine starts but with
loss ofpower.
• Wrong choke setting. Openthechoke.
• Dirty air filter. Cleanor change theair filter.
• Dirt in thecarburettor. Getaqualified technician to clean thecarburettor.
The engine doesn’t respond
to thethrottle.
• Engine not adequately warmed up. Allowtheengine to idle for aminute.
Loss of power underload. • Faulty spark plug. Cleanor change thesparkplug.
The engine runs irregularly. • Dirt in thecarburettor. Getaqualified technician to clean thecarburettor.
Disposal
This product should be disposed of in accordance with local regulations. Ifyou are unsure how to proceed,
contact your local authority.
Specifications
Brush cutter blade 255mm
Trimmer line 2.4mm
Engine capacity 35.8cc
Power 1.0 kW (1.36 hp)
Weight 8.4kg
Fuel tank capacity 0.65l
Engine oil capacity 0.1l
Engine speed 9300rpm
Noise level LwA,d = 113 dB(A), K = 1.95 dB(A)
Vibration level with brush cutter blade at idle speed: left handle 1,619 m/s², right handle 1,440 m/s².
Vibration level with brush cutter blade at full throttle: left handle 5,190 m/s², right handle 3,043 m/s².
Vibration level with trimmer head at idle speed: left handle 1,639 m/s², right handle 1,432 m/s².
Vibration level with trimmer head at full throttle: left handle 6,187 m/s², right handle 5,696 m/s².
Uncertainty: K = 1,5 m/s²
