When level planing, theextraction hood (E) must be mounted as it acts as acover!
1. Lower thetable (J) as far as itcan.
2. Loosen thearm (F) holding thecutter cover (K) and unfold it.
3. Pull both locking levers (H) on theextraction hood.
4. Push in theextraction hood under thelevelling table so that
thelocking levers (H) fit thevents in thelevelling table (G); push in
thelocking levers (H).
6.3 Setting cutter cover
1. Loosen thelocking wheel holding thearm (F) and lift to thecorrect
height (the material’s thickness); tighten thelocking wheel.
2. Press thecover against thematerial so that it covers thecutter’s
free parts, or place above thematerial if it iswide.
3. Tighten thecover’s locking wheel.
6.4 Level planing
1. Mounting theextraction hood.
2. Set thedesired cutting depth with thewheel (L); settings of thefeeding table (N) are shown on theshell (M)
(clockwise = decrease, counter-clockwise = increase).
3. Cutting depth of 0.5–1.5 mm provides thebest surface. Warning! Position thecutter cover so that it covers
thecutter’s freeparts.
4. Press theboard against thefeeding table and position thecutter cover at thesame height as theleft hand
(the board should easily go through thegap). Startthemotor and let it rev up then slowly and carefully feed
theboard through over thecutter. Allowhands to move over thecutter cover.
6.5 Surface planing
1. Mount theextraction hood (E) above thelevelling table.
2. Set desired dimension for thematerial with thecrank (O)
(1 turn = 3 mm), feed thematerial’s thickness and set
theplaning thickness 1–2 mm less and make thefirst
planecut.
3. Start themotor and let it rev up then slowly and carefully
feed onto theplaning table with thelevel planing side facing
downwards.
4. Slowly push theboard inwards until thefeeding roller grips
theboard. Iftheboard is wedge-shaped put thethicker end
in first.
Warning! Neverplane short material, feed in narrow materials in
themiddle of thewidth of thecutter. Makesure thecable moves
freely and does not get tangled in thecutter.
