Important: Always read and follow the instructions. • 13
Match Mount
- This function serves to reduce the amount of weight
to be added in order to balance the wheel.
- It is suitable for static unbalance exceeding 1.5 oz
(30g).
- It improves the residual eccentricity of the tire.
- Mark with chalk a reference point on the adapter and
rim.
- With the aid of a tire remover, turn the rim on the tire
by 180°.
- Refit the wheel with the reference mark coinciding
between rim and adapter.
- RH display: percentage reduction.
- LH display: actual static unbalance which can be
reduced by rotation
- Mark the two positions of the rim and tire, and turn
the rim on the tire until the positions correspond in
order to obtain the optimization on the display.
CANCEL OPTIMIZATION IN ANY PHASE.
Unbalance
already measured
Unbalance measured
Tire Position
Rim Position
Possible
Tire Position =
Rim Position
No previous
unbalance
measurement
RETURN TO
START OF
OPTIMIZATION
