COBHAM 7023A User Manual

98-175666-A Appendix A: Technical specifications A-3
Specifications (100 cm antenna)
Compass safe distance 1.5 m / 59” to EN60945
Maintenance, scheduled None
Maintenance, unscheduled All modules, motor, RF parts and belts are replaceable through service
hatch
Built In Test Power On Self-Test, Person Activated Self-Test and Continuous Monitoring
w. error logging
Dimensions Height: H 150 cm / 59”
Diameter: Ø 130 cm / 51.2”
Weight 105 kg / 231 lb
BELOW-DECK UNIT (BDU)
Dimensions 1U 19” rack mount
HxWxD: 4.4 x 48 x 33 cm / 1.73” x 18.9” x 13”
Weight 3.6 kg / 8 lb
Temperature (ambient) Operational: -25ºC to +55ºC / -)WR)
Storage: -40ºC to +85ºC / -)WR)
Humidity EN60945 Protected, 95% (non-condensing)
IP class IP30
Compass safe distance 0.3 m / 12” to EN60945
Interfaces 1 x N-&RQQHFWRUIRUDQWHQQD5)&DEOHƻZLWKDXWRPDWLFFDEOHORVV
compensation
2 x F-&RQQHFWRUVƻIRU5[DQG7[WR96$7PRGHP
1 x Ethernet Data (VSAT Modem Control)
2 x Ethernet (User)
1 x Ethernet (Remote access)
1 x Ethernet for Service and Configuration
1 x RJ-45, RS-422 Data (VSAT Modem Control)
1 x RJ-45, RS-232 Data (VSAT Modem Control)
1 x RJ-45, NMEA 0183 (RS-422 / RS-232) for Gyro/GPS Compass and
external GPS input
1 x RJ-45, 4 x General purpose GPIO, Tx mute and Rx lock.
1 x AC power input
1 x Grounding bolt
User interface Webserver, OLED display (red), 5 pushbuttons, 3 discrete indicator LEDs
and On/Off switch, TX Mute and Modem Lock indicator.
Temperature control Built-in fan
No transmit zones Programmable, 8 zones with azimuth and elevation
Real-time blocking map recorder
Remote management and IoT HTTPS, SSH, Telnet, SNMP Traps, Syslog, CLI, Diagnostic, Statistic,
RESTful, MQTT
VSAT MODEM SUPPORT
Modem protocols Generic, OpenAMIP, OpenBMIP, Custom protocol
Modem hardware SAILOR GX Modem
SAILOR GX MODEM UNIT
(GMU)
Dimensions 1U 19” rack mount
HxWxD: 4.4 x 48 x 33 cm / 1.73” x 18.9” x 13”
Weight 3.5 kg / 7.7 lb
Humidity EN60945 Protected, 95% (non-condensing)
IP class IP30
Compass safe distance 0.4 m / 16” to EN60945
Interfaces 2 x F-&RQQHFWRUVIRU5[DQG7[WR%'8
1 x RJ-45 Ethernet for control and user data, routes through BDU
1 x RS-422 (Modem Control)
1 x RS-232 Data (Modem Control)
1 x RS-232 Modem console
1 x AC power input
1 x Grounding bolt
Input power 100 - 240 VAC, 50-60 Hz, 90 W peak, 30 W typical
Modem interface control OpenAMIP, OpenBMIP, RS-422 and RS-232
User interface Web MMI, On/Off switch and power LED
Temperature control Built-in fan and heater
