COBHAM 7023A User Manual

98-175666-A Appendix F: Event messages F-5
List of events
08523-0 ADM ERROR Ele axis calibration Elevation axis zero reference or end stops not
found at expected locations. Check belt, zero
reference module, and end stops. Info: See 08521-
0.
08524-0 ADM ERROR Pol axis calibration Polarisation axis zero reference or end stops not
found at expected locations. Check movement of
the polarisation unit and the zero reference
module. Info: See 08521-0. (!T,!G)
08525-0 ADM ERROR Antenna calibration One or more errors occurred during antenna start-
up Info: 0x00000001: Timeout (calibration did not
complete in time) 0x00000010: Azimuth axis
0x00000020: Cross-elevation axis
0x00000040: Elevation axis 0x00000080:
Polarisation axis
08534-0 ADM WARNING ACU communication The communication link between ACU and antenna
is not working.
08535-0 ADM WARNING ISM data valid Sensor measurements from the ISM are invalid.
This indicates a malfunctioning ISM.
08536-0 ADM WARNING ISM data range Sensor measurements from the ISM are out of
range.
08537-0 ADM WARNING GNSS communication Lost connection to the GNSS device.
08538-0 ADM WARNING GNSS data range Received information from the GNSS device which
is out of range.
08539-0 ADM WARNING GNSS device warning Local GNSS device warning.
0853A-0 ADM WARNING GNSS device error Local GNSS device error.
0853F-0 ADM WARNING AMB timing This indicates a busy situation. It may occur during
installation procedures. No user interaction is
required unless it occurs repeatedly.
08540-0 ADM WARNING VIM cable attn The output power cannot be controlled correctly.
Check the Tx chain. (!T)
08541-0 ADM WARNING BUC voltage low The voltage for the BUC is too low, probably caused
by a malfunctioning VIM or BUC. (!T,!G)
08542-0 ADM WARNING BUC voltage high The voltage for the BUC is too high probably
caused by a malfunctioning VIM. (!T,!G)
08543-0 ADM WARNING LNB voltage low The voltage for the LNB is too low probably caused
by a malfunctioning VIM or LNB.
08544-0 ADM WARNING LNB voltage high The voltage for the LNB is too high probably caused
by a malfunctioning VIM.
08546-0 ADM WARNING Antenna temperature The temperature of the antenna is too high. Check
if the fan is working. (!T,!G)
ID Module Type Description Explanation
Table F-1: Event messages (Continued)
