COBHAM 7023A User Manual

98-175666-A Appendix F: Event messages F-8
List of events
08842-0 ADM WARNING GSC demodulator The GSC demodulator has reported an error. (!V,!T)
08843-0 ADM WARNING DVBS demodulator The DVBS demodulator cannot be initialised and
loaded correctly. (!V,!T)
08844-0 ADM ERROR BUC voltage out of
range
The BUC voltage is out of range. (!V,!T)
08845-0 ADM ERROR LNB voltage out of
range
The LNB voltage is out of range. The LNB might be
switched off to protect the power supply circuitry.
Reactivate satellite profile to try again, check LNB
cable and surroundings if the problem persists.
(!V,!T)
08846-0 ADM ERROR AIM-O supply voltage
out of range
Supply voltage measured at AIM-O is not within
expected range (!V,!T)
08847-0 ADM ERROR AIM-O Master PLL
lock
The AIMO master PLL has lost lock. Check the input
reference signal. (!T)
08848-0 ADM WARNING TX Calibration
missing
Tx calibration not performed. (!T)
08880-0 ADM ERROR WLAN configuration
error
Configuration of WLAN module failed. (!V,!T)
08881-0 ADM WARNING DHCP Client address An IP address was received from an external DHCP
server that overlaps another VLAN. Traffic on these
VLANs may be unpredictable. Reconfigure the
server or IP settings of that VLAN.
08A00-0 ADM WARNING GX Core Module fan There is a problem with the Core Module fan.
Check/clean and replace if necessary. (!V,!T)
08A01-0 ADM WARNING GX Core Module
heater
There is a problem with the Core Module heater.
Check and replace if necessary. (!V,!T)
08A02-0 ADM WARNING GX Core Module
temperature
The Core Module temperature is out of range. This
may affect performance, and the Core Module will
be shut down if the situation gets worse. If the "GX
core module heating" event is also present, the
internal heater is currently warming up the unit to
its operational temperature. (!V,!T)
08A03-0 ADM ERROR GX Core Module
power
The Power Good signal from the Core Module is
low. The issue can either be: - Internal Core Module
or internal cable failure - Temperature of Core
Module is too high and it has been turned off (*) -
GMU has been manually switched off on the front
panel (*) (*) = Only on systems with GMU. (!V,!T)
ID Module Type Description Explanation
Table F-1: Event messages (Continued)
