COBHAM 7023A User Manual

98-175666-A Appendix F: Event messages F-13
List of events
0B094-0 APSM INFO APSM Main Over
voltage protection
Voltage too high. (!T,!S)
0B0A0-0 APSM ERROR APSM
Communication error
No communication with APSM. Check internal
connections in ACM. (!T,!S)
0B0A1-0 APSM ERROR BDCM
Communication error
No communication with BDCM. Check main
antenna cable. (!T,!S)
0D000-0 BDCM WARNING BDU PSU
temperature too high
BDU PSU temperature too high.
0D001-0 BDCM WARNING BDU PSU fan does
not work
BDU PSU fan does not work.
0D002-0 BDCM ERROR BDU PSU will
shutdown
BDU PSU will shutdown.
0D003-0 BDCM ERROR BDCM prod data BDCM prod data is invalid
0E000-0 AIMO ERROR AIM-O
Communication
Startup of communication with AIM-O failed.
0E001-0 AIMO ERROR AIM-O PLL out of lock PLL out of lock
0E002-0 AIMO ERROR AIM-O voltage range Voltage measured at AIM-O is not within expected
range
0E003-0 AIMO ERROR AIM-O cal data AIM-O calibration data is invalid
0F000-0 BIMO ERROR BIM-O
Communication
Startup of communication with BIM-O failed.
0F001-0 BIMO ERROR BIM-O PLL out of lock PLL out of lock
0F002-0 BIMO ERROR BIM-O voltage range Voltage measured at BIM-O is not within expected
range
0F003-0 BIMO ERROR BIM-O cal data BIM-O calibration data is invalid
0F004-0 BIMO ERROR VMU reference signal There is no VMU Rx or Tx reference signal. Whether
this is Rx or Tx reference depends on the user's
selection on the modem profile page in the web
interface. Make sure the VMU Rx/Tx cable is
connected and that the VMU is configured to
output the RX/TX reference signal.
0F005-0 BIMO WARNING No BIMO Master PLL BIMO Master PLL out of lock
0F006-0 BIMO WARNING No BIMO LO PLL BIMO LO PLL out of lock
ID Module Type Description Explanation
Table F-1: Event messages (Continued)
