Appendix A: Specifications
98-169085-B EXPLORER 323 terminal 115
Environmental specifications
Characteristics Specification
Water and dust IP66 (with cable inserted)
Ambient temperature
Operating
Survival
Storage
-25°C to +55°C at min. 1 m/s windload
-40°C to +80°C
-40°C to +85°C
Relative humidity up to 95% non-condensing at 40°C
Ice, survival Up to 25 mm of ice (non-operational)
Wind Relative wind speeds up to 200 km/h
Vibration, operational Random vibration of 1.05 G RMS in each of three mutually
perpendicular axes.
The spectrum of the vibration is as follows:
• 5 to 20 Hz: 0.02 G
2
/Hz
•20 to 150 Hz: -3dB/octave
Vibration, survival Random vibration of 1.7 G RMS for a period of two hours in
each of three mutually perpendicular axes (six hours total).
The spectrum of the vibration is as follows:
• 5 to 20 Hz: 0.05 G
2
/Hz
•20 to 150 Hz: -3dB/octave
Vehicle motion Turning rate: 40°/s
Turning acceleration: 50°/s²
Induced acceleration: 0.5 G
Velocity: Maximum vehicle velocity 110 km/h with the
Magnetic Mount Solution, 200 km/h for bolt mounting.
Shock, survival Half sine wave shock with a peak of 20 G and a period of
11 ms.
