Chapter 1: Introduction
2Features
1.2 Features
The SAILOR 6080 Power Supply has the following features:
Two DC connectors, output, range: 28.7 V - 31.2 V
Output power 300 W continuous, 370 W peak (max. 2 min., 10% duty
cycle, 100-240 VAC) or 270 W continuous, 333 W peak (max. 2 min.,
10% duty cycle, 90-100 VAC)
Daisy-chaining of up to four units to give up to 1480 W.
1
AC input (100-240 VAC operating) with fuse (6.3 A) with Power Factor
Correction
Automatic detection of input voltage range
AC alarm and Short circuit protection
Over-temperature protection (shutdown with automatic restart)
Switch over to battery power in case of AC supply failure
On/off switch
IP 30 protection
Approval and certification: IEC 60945 approval
1. Output power capability depends on the mounting position (horizontal or
vertical), input voltage, ambient temperature and ventilation at the place of
installation.
