Appendix C
CCCC
Wiring 3 or more
SAILOR 6080 units C
If you need more than 2x300 W or 20 A you can connect three or more
SAILOR 6080 Power Supply units.
You must connect the units as shown in the drawing. This is
to make sure that a single connector is never overloaded
with more than 20 A.
Connected user equipment normally requires the cable resistance
to be as low as possible. Refer to the specifications for your
connected equipment to find the right cables for your installation.
(PHUJHQF\
%DWWHU\
77$ 77$ 77$ 77$
)XVH
8VHU
8VHU
'&
8VHHTXDOOHQJWKVDQG
FURVVVHFWLRQVIRUDOO
FDEOHVEHWZHHQWKH
EDWWHU\DQGWKH
6$,/25V
