Cobra 29 LX EU User Manual

Ch. No. Freq.(MHz)
1 26.965
2 26.975
3 26.985
4 27.005
5 27.015
6 27.025
7 27.035
8 27.055
9 27.065
10 27.075
11 27.085
12 27.105
13 27.115
14 27.125
15 27.135
16 27.155
17 27.165
18 27.175
19 27.185
20 27.205
21 27.215
22 27.225
23 27.255
24 27.235
25 27.245
26 27.265
27 27.275
28 27.285
29 27.295
30 27.305
31 27.315
32 27.325
33 27.335
34 27.345
35 27.355
36 27.365
37 27.375
38 27.385
39 27.395
40 27.405
Frequency Ranges continued
3736
29 LX EU Specifications
GENERAL
Channels ......................................................FM/AM
Frequency Range .....................................26.565 to 27.99125 MHZ
Frequency Tolerance ..............................0.005 %
Frequency Control ..................................PLL (Phase Lock Loop) Synthesizer
Operating Temperature Range ...........-30° C TO + 65° C
Microphone ................................................Plug-in dynamic
Input Voltage ............................................13.2 VDC nom. (negative ground)
Current Drain .............................................Transmit: AM/FM full mod., 1.4A (maximum)
Receive: Squelched, 0.9 A;
Full audio output, 1.2A (nominal)
Maximum Duty Cycle ............................ 5 minute transmit
5 minute stand-by
Size ..............................................................8.625”D x 7.28125”W x 2.8125”H
Weight ..........................................................4 lbs.
Antenna Connector ................................. UHF; SO-239
Meter .............................................................LCDs; indicates relative power
output and received signal strength
TRANSMITTER
Power Output ............................................4 watts FM, 4/1 watt AM
Modulation .................................................AM (Amplitude Modulation)
FM (Frequency Modulation)
Frequency Response ...............................300 to 3000 Hz
Output Impedance ..................................50 ohms, unbalanced
RECEIVER
Sensitivity ....................................................Less than 1 µV for 10 dB (S+N) /N
Selectivity ....................................................6 dB @ 7 KHz, 60 dB @ 10KHz
Image Rejection ........................................80 dB, typical
Adjacent-Channel Rejection ................60 dB, typical
IF Frequencies ...........................................Double Conversion: 1st: 10.695 MHz
2nd: 455 KHz
Automatic Gain Control (AGC) ............Less than 10 dB change in audio
output for inputs from 10 to 50,000
microvolts
RF Gain range ............................................40 db
Noise Blanker .............................................RF type
Squelch ........................................................Adjustable; threshold less than 1µV
Audio Output Power ...............................4 watts
Frequency Response ...............................300 to 3000 Hz
Distortion ....................................................Less than 7% @3 watts @ 1000 Hz
Built-in Speaker .........................................8 ohms, 5w
External Speaker (Not supplied)............ 8 ohms; disables internal speaker
when connected
(SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE)
Ch. No. Freq.(MHz)
1 26.965
2 26.975
3 26.985
4 27.005
5 27.015
6 27.025
7 27.035
8 27.055
9 27.065
10 27.075
11 27.085
12 27.105
13 27.115
14 27.125
15 27.135
16 27.155
17 27.165
18 27.175
19 27.185
20 27.205
21 27.215
22 27.225
23 27.255
24 27.245
25 27.265
26 26.875
27 26.885
28 26.895
29 26.905
30 26.915
31 26.925
32 26.935
33 26.945
34 26.955
35 26.855
36 26.865
Ch. No. Freq.(MHz)
1 26.965
2 26.975
3 26.985
4 27.005
5 27.015
6 27.025
7 27.035
8 27.055
9 27.065
10 27.075
11 27.085
12 27.105
13 27.115
14 27.125
15 27.135
16 27.155
17 27.165
18 27.175
19 27.185
20 27.205
21 27.215
22 27.225
23 27.255
24 27.235
25 27.245
26 27.265
27 27.275
28 27.285
29 27.295
30 27.305
31 27.315
32 27.325
33 27.335
34 27.345
35 27.355
36 27.365
37 27.375
38 27.385
39 27.395
40 27.405
Ch. No. Freq.(MHz)
41 26.565
42 26.575
43 26.585
44 26.595
45 26.605
46 26.615
47 26.625
48 26.635
49 26.645
50 26.655
51 26.665
52 26.675
53 26.685
54 26.695
55 26.705
56 26.715
57 26.725
58 26.735
59 26.745
60 26.755
61 26.765
62 26.775
63 26.785
64 26.795
65 26.805
66 26.815
67 26.825
68 26.835
69 26.845
70 26.855
71 26.865
72 26.875
73 26.885
74 26.895
75 26.905
76 26.915
77 26.925
78 26.935
79 26.945
80 26.955
Band ID I2:
Italy 2
AM 4.0W
FM 4.0W
Band ID DE:
Germany
40 CH AM 1.0W
80 CH FM 4.0W
Trademark Acknowledgement
Cobra®, Nothing Comes Close to a Cobra® and the snake design are registered trademarks of
Cobra Electronics Corporation, USA. Cobra Electronics Corporation™ is a trademark of Cobra
Electronics Corporation, USA.
Band ID I1:
Italy 1
AM 4.0W
FM 4.0W
Ch. No. Freq.(MHz)
1 26.965
2 26.975
3 26.985
4 27.005
5 27.015
6 27.025
7 27.035
8 27.055
9 27.065
10 27.075
11 27.085
12 27.105
13 27.115
14 27.125
15 27.135
16 27.155
17 27.165
18 27.175
19 27.185
20 27.205
21 27.215
22 27.225
23 27.255
24 27.235
25 27.245
26 27.265
27 27.275
28 27.285
29 27.295
30 27.305
31 27.315
32 27.325
33 27.335
34 27.345
35 27.355
36 27.365
37 27.375
38 27.385
39 27.395
40 27.405
Band ID EU:
France
AM 1.0W
FM 4.0W
29LXEU_MANL_ENG_vD.indd 36-37 1/11/12 10:09 AM
