Cobra CDR 820 User Manual

English
10 11
To play or pause video playback
Press the RECORD
button.
The video will begin playing or
pause playback, and the Play /
Pause icon will toggle.
To Fast forward or rewind the video
Press the UP or
DOWN buttons.
The video will begin playing
faster or rewind, and the
playback speed will show on
the screen as 2X, 4X, etc.
To return to the list of saved les while in the middle of video playback
Press the MODE button. You will be returned to the video selection
screen.
File Name
00:01:37 / 00:10:00MOV_0001.AVI
Play/Pause Icon
6/34
File Number
Battery Level
SD Card
Video Length &
Time Elapsed
Video Playback Screen
To adjust the playback audio volume
Press MENU to bring up the Playback menu.
Make sure VOLUME is highlighted, and press
MODE.
Press the arrow keys to select a volume
level, 0-10. The selected volume level will
have a red box around it. Press MODE again
to conrm and close. Finally, press MENU
to exit.
To delete a le
Press the MENU button to bring up the
Playback menu. Press the down arrow to
highlight DELETE, and press MODE to
conrm.
To delete just one le, highlight the icon with
just one item in the trash, and press MODE
to conrm. You will then see the “select a
le” dialog. Use the arrow keys to highlight
the le you want to delete with the red box,
then press RECORD to conrm. The “Delete
Selected File” Dialog will appear. Make sure
YES is selected, and then press RECORD to
conrm. The le will be deleted and you will
return to the video selection screen.
Device Operation
Your Dash Cam
Device Operation
Your Dash Cam

Cobra CDR 820 Specifications

General

Product color	Black
White balance	Auto
G-shock sensor	Yes
GPS (satellite)	No
Languages support	RUS, CHI (SIMPL), DEU, DUT, ENG, ESP, FRE, POR
Number of cameras	1
Main camera sensor	CMOS
Maximum frame rate	60 fps
Main camera resolution	1920 x 1080 pixels
Main camera viewing angle	118 °
Video compression formats	AVI, H.264
Main camera sensor resolution	5 MP
Display diagonal	1.5 \
Built-in storage media	-
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	32 GB
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Power source type	Battery, Cigar lighter
Image formats supported	JPG
Maximum image resolution	4032 x 3094 pixels
Cables included	USB
Included memory card size	8 GB

Weight and Dimensions

Depth	38.1 mm
Width	45.72 mm
Weight	38 g
