Cobra CDR855BT User Manual

11 | P a g e
VIDEO SCREEN
The Video Screen is the home screen for the device and allows you to easily record HD video of
the road ahead of you.
STATUS BAR ICONS:
A. Recording Icon. When recording dual camera videos the icon will appear.
B. Indicates the recording time of the current clip.
C. The hazard icon appears if an Emergency Recording is active. If GPS is plugged in a gray
GPS icon will appear. The GPS icon will turn white when GPS lock is achieved.
D. Indicates whether the mic is active or muted.
E. Shows if Parking Mode is on.
F. Bluetooth indicator shows gray if Bluetooth is turned on and white if Bluetooth is on and
connected to the Cobra iRadar app.
G. Indicates battery level or charging indicator when power is applied to the camera.
VIDEO SCREEN BASICS:
When first powered on, the device will start on the video screen and automatically begin
recording.
Press the Record/Pause button to stop and start recording.
Note that the button functions are different depending on whether the unit is currently
recording or not.
Also note that the unit must be paused in order to enter the Settings Menu.
A
B
C
D
E
F
G

Cobra CDR855BT Specifications

General

Product color	Black, Grey
White balance	Auto
G-shock sensor	Yes
GPS (satellite)	-
Languages support	CHI (SIMPL), DEU, DUT, ENG, ESP, FRE, POR, RUS
Number of cameras	1
Main camera sensor	CMOS
Maximum frame rate	60 fps
Main camera resolution	1920 x 1080 pixels
Main camera viewing angle	160 °
Video compression formats	MOV
Main camera sensor resolution	2 MP
Image formats supported	JPG
Built-in storage media	No
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	32 GB
Cables included	Micro-USB, USB
Included memory card size	8 GB
Display diagonal	2 \
Power source type	Battery, Cigar lighter
Input operation voltage (max)	12 V

Weight and Dimensions

Depth	31.6 mm
Width	65 mm
Height	58 mm
