Coca-Cola Freestyle - Equipment Overview; Dispenser Components

Nozzle tip and injector ring
4 | ©2020 McDonald’s | ©2020 The Coca-Cola Company | Freestyle at McDonald’s | User Guide | Confi dential
1
Touch screen
2
Nozzle tip and injector ring
3
Beverage dispense lever
4
RFID scanner
5
ADA interface
6
Ingredient cartridges
(unagitated)
7
Ingredient cartridges
(agitated)
8
Power switch
Dispenser
Components
Equipment Overview
Power Switch
The power (on/o ) switch is located at
top center right corner. CAUTION! DO
NOT POWER OFF unless instructed to
do so by a Coca-Cola technician.
Dispenser (Door Closed) Dispenser
(Door Open)
1
2
3
5
4
6 6
7
8
