13 Connecting Auxiliary Devices
page 19 of 45 GU-139-Z1
The IA4100 speakerphone analog auxiliary connections are three normally open or three
normally closed outputs and two normally open inputs. Typically, any Code Blue unit with a
LED beacon/ strobe will have the trigger connected to Auxiliary Output 1. The Auxiliary
Outputs can be programmed to be active during a call or by entering a specific time
period. The Auxiliary Inputs can be programmed to perform any script entered into the
phone. Auxiliary inputs require power utilizing any voltage between 9 and 32 volts AC or
DC.
IA4100
Administrator Guide
