Code Blue IA4100 - Commands During a Call

page 24 of 45 GU-139-Z1
The following commands may be used by the called party after the IA4100 places a call, or
by calling into the IA4100 and entering audio modes 3, 4 or 5. The commands below
cannot be used while in programming mode. When issuing a two-digit command, the
second digit must follow the first by no more than 0.7 seconds. Failure to complete the
command will result in a DTMF “BB” NAK (double beep or rejected tones).
These commands cannot be used in Programming Mode.
16.2 Commands During a Call
Play Recordings
NOTE: To stop message playback, press # pound) during
the message playback. When the message is finished, the
user will hear a single tone (DTMF “#”) to signal the end
of message.
Audio Adjustments
NOTES: If the audio level being changed has reached its maxi-
mum or minimum, you will hear two tones (DTMF “BB”).
Microphone/Speaker/PAS audio level changes will be
retained
until changed or the audio gains are reset (See Programming
Commands: Pass Codes and Reset Programming, Commands
95 and 99; page 16).
Microphone or speaker can be toggled between their current
level and mute by issuing Commands 24 or 25.
When a mute command is entered, you will either hear a
single
tone (DTMF “B”) to indicate NOT muted or a double tone
(DTMF “BB”) to indicate a muted condition.
Turn On/Off Outputs
NOTES: After entering ** or **# you will have seven seconds
to enter a new initial call in command and password if
applicable.
After seven seconds with no entry, the IA4100 will hang up.
NOTE: The Call Timer is extended by Call Time Out
minutes. (Programming command 44). After this
command is entered, the user will hear a single tone
(DTMF “B”) acceptance.
End Call
NOTES: When an auxiliary output is initiated, it will remain on
for the duration of the timed programming or until turned off
using Commands 14, 15 or 16 (See Commands 11, 12 and 13).
Normally Closed (N.C.) and Normally Open (N.O.) state
changes mare separated by 10 milliseconds on each output;
they do not happen simultaneously. This is to ensure both the
N.C. and N.O. contacts are never closed at the same time.
Miscellaneous
Command
Command
Explanation
Explanation
Format
Format
Command
Command
Command
Explanation
Explanation
Explanation
Format
Format
Format Default
01
02
03
04
05
06
07
08
09
20
21
22
23
24
25
28
29
Play message number 1
Play message number 2
Play message number 3
Play message number 4
Play message number 5
Play message number 6
Play message number 7
Play message number 8
Play message number 9
Increase microphone gain by
3 dB
Decrease microphone gain
by 3 dB
Speaker volume up
Speaker volume down
Microphone mute toggle
Speaker mute toggle
PAS output volume increase
PAS output volume decrease
01
02
03
04
05
06
07
08
09
20
21
22
23
24
25
28
29
11
12
13
14
15
16
31
33
*#
Hang up IA4100
Extend Call Timer
Terminate message
playback
Change from
Monitor (3-5) or
Paging (9) Mode to
Programming Mode
Change from
Programming Mode
to Monitor (3-5) or
Paging (9) Mode
31
33
Turn on auxiliary output 1
Turn on auxiliary output 2
Turn on auxiliary output 3
Turn off auxiliary output 1
Turn off auxiliary output 2
Turn off auxiliary output 3
11
12
13
14
15
16
*#
10
minutes
* * #
* *
* * #
* *
IA4100
Administrator Guide
