15.0 - Reader Pinouts
The connector on the CR1000 is an RJ-50
(10P-10C). The pinouts are as follows:
Pin 1 +VIN (5v)
Pin 2 USB_DM
Pin 3 USB_DP
Pin 4 RS232 TX (output from reader)
Pin 5 RS232 RTS (output from reader)
Pin 6 RS232 RX (input to reader)
Pin 7 RS232 CTS (input to reader)
Pin 8 External Trigger (active low input to reader)
Pin 9 N/C
Pin 10 Ground
16.0 - CR1000 Maintenance
The CR1000 device needs only a minimum of maintenance to operate. A few tips are given below for maintenance suggestions.
Cleaning the CR1000 Window
CR1000 window should be clean to allow the best performance of the device. The window is the clear plastic piece inside the head of
the reader. Do not touch the window. Your CR1000 uses CMOS technology that is much like a digital camera. A dirty window may stop
the CR1000 from reading barcodes.
If the window becomes dirty, clean it with a soft, non-abrasive cloth or a facial tissue (no lotions or additives) that has been moistened
with water. A mild detergent may be used to clean the window, but the window should be wiped with a water moistened cloth or tissue
after using the detergent.
Technical Support and Returns
For returns or technical support call Code Technical Support at (801) 495-2200. For all returns Code will issue an RMA number which
must be placed on the packing slip when the reader is returned. Visit www.codecorp.com/codesupport.php for more information.
