Code CR1000 User Manual

6
C005905_06_CR1000_UserManual
6.0 - Reading Ranges
Note: Working ranges are a combination of both the wide and high density elds. All samples were high quality barcodes and were read along a
physical center line at a 10° angle. Default AGC settings were used. Accuracy= +/- 10%.
4.0 - Using a CR1000
Out of a Stand
5.0 - Using a CR1000
In a Stand
CR1000 Performance
Test Barcode Min Inches (mm) Max Inches (mm)
3 mil Code 39 3.1” (80 mm) 4.0” (102 mm)
7.5 mil Code 39 1.3” (33 mm) 7.2” (182 mm)
10.5 mil GS1 DataBar 0.8” (20 mm) 8.7” (220 mm)
13 mil UPC 1.1” (28 mm) 11.0” (280 mm)
5 mil DM 1.7” (43 mm) 4.5” (115 mm)
6.3 mil DM 1.3” (33 mm) 5.9” (150 mm)
10 mil DM 0.8” (20 mm) 7.1” (180 mm)
20.8 mil DM 1.1” (28 mm) 13.5” (343 mm)
10 cm
10 cm
