Code CR1500 User Manual

3
D030210_01_CR1500_User_Manual
Table of Contents
1.0 - CR1500 Readers and Accessories ................................................................3
2.0 - Unpacking..................................................................................................4
3.0 - Attaching and Detaching a Cable...................................................................5
4.0 - Set Up........................................................................................................5
5.0 - Using a CR1500 out of a Universal Stand......................................................6
6.0 - Using a CR1500 in a Universal Stand ...........................................................6
7.0 - Reading Ranges...........................................................................................6
8.0 - Reader Feedback.........................................................................................7
9.0 - Symbologies Defaulted On............................................................................7
10.0 - Symbologies Defaulted Off..........................................................................7
11.0 - Reader ID & Firmware Version.....................................................................8
12.0 - CR1500 Overall Dimensions.......................................................................8
13.0 - USB Cable Example with Pinouts................................................................9
14.0 - RS232 Cable Example with Pinouts.............................................................9
15.0 - Reader Pinouts..........................................................................................9
16.0 - CR1500 Maintenance..............................................................................10
17.0 - Online Resources for the CR1500.............................................................10
18.0 - Warranty..................................................................................................11
1.0 CR1500 Readers and Accessories
Model Number-Version Description
CR1500-K10x CR1500 Reader, Cabled, Light Gray, CodeShield
CR1500-K20x CR1500 Reader, Cabled, Dark Gray
CR1500-L20x CR1500 DPM Reader, Cabled, Dark Gray
CR1500-M20x CR1500 XHD Reader, Cabled, Dark Gray
Cables Description
Refer to www.codecorp.com/cables.php for a complete list of available cables.
CR1500 Accessories
Product SKU Description
CRA-US2 Goose-Neck Stand, Light Gray
CRA-US3 Goose-Neck Stand, Dark Gray
CRA-WMB3 Wall Mount Bracket, Light Gray
CRA-MB9 Clamp Mount
D030210_04_CR1500_User_Manual

Code CR1500 Specifications

General

Brand	Code
Model	CR1500
Category	Barcode Reader
Language	English
