Code CR1500 - Using a CR1500 out of a Stand; Using a CR1500 in a Stand; Typical Reading Ranges

6
D030210_01_CR1500_User_Manual
10 cm
7.0 - Typical Reading Ranges
5.0 - Using a CR1500
out of a Stand
6.0 - Using a CR1500
in a Stand
Note: Working ranges are a combination of both the wide and high density fields. All samples were high quality codes and were read along a
physical center line at a 10° angle. Default automatic gain control settings were used with regular office lighting. Accuracy= +/- 10%. Testing
conditions may affect working ranges. Measured from the front of the device in metric units then converted to Imperial units.
10 cm
D030210_04_CR1500_User_Manual
Test Barcode Min Inches (mm) / Max Inches (mm)
Min Inches (mm) / Max Inches (mm) Min Inches (mm) / Max Inches (mm)
CR1500-KXXX (Standard) CR1500-L2XX (DPM) CR1500-M2XX (XHD)
0.2” (5 mm) / 8.1” (205 mm)
3.3” (85 mm) / 4.2” (107 mm)
0.7” (18 mm) / 6.6” (167 mm)
0.5” (13 mm) / 10.4” (265 mm)
1.1” (28 mm) / 3.9” (100 mm)
0.7” (18 mm) / 5.3” (135 mm)
0.2” (5 mm) / 6.5” (165 mm)
0.5” (13 mm) / 12.9” (328 mm)
3 mil Code 39
5.8 mil PDF417
7.5 mil Code 39
10.5 mil GS1 DataBar
13 mil Code 128
3.3 mil Data Matrix
4.2 mil Data Matrix
5 mil Data Matrix
6.3 mil Data Matrix
10 mil Data Matrix
20.8 mil Data Matrix
0.9” (24 mm) / 6.7” (170 mm)
0.2” (5 mm) / 6.1” (155 mm)
0.7” (17 mm) / 9.6” (245 mm)
1.0” (25 mm) / 2.4” (60 mm)
0.8” (20 mm) / 2.8” (70 mm)
0.5” (12 mm) / 3.6” (92 mm)
0.2” (5 mm) / 5.9” (150 mm)
0.4” (10 mm) / 10.4” (265 mm)
0.6” (14 mm) / 1.5” (39 mm)
0.4” (9 mm) / 1.7” (44 mm)
1.4” (35 mm) / 2.3” (58 mm)
0.6” (15 mm) / 2.8” (71 mm)
1.2” (31 mm) / 3.3” (83 mm)
0.4” (11 mm) / 1.1” (29 mm)
0.4” (9 mm) / 1.2” (31 mm)
0.4” (9 mm) / 1.5” (39 mm)
0.3” (7 mm) / 1.6” (41 mm)
0.3” (7 mm) / 2.1” (54 mm)
0.3” (7 mm) / 3.6” (92 mm)
