Code CR5200 User Manual

10
D041878 CR5200 User Manual
13.0 - CR5200 Overall Dimensions
3.55"
(90.30 mm)
2.80"
(71.23 mm)
5.95"
(151.14 mm)
14.0 - USB Cable Example with Pinouts
NOTES:
1. Part to be ROHS and Reach compliant.
2. Maximum Voltage Tolerance = 5V +/- 10%.
3. Caution: Exceeding the maximum voltage will void
manufacturer warranty.
CONNECTOR A CONNECTOR B
CONNECTOR A NAME CONNECTOR B
1 VIN 1
2 D- 2
3 D+ 3
4 GND 10
SHELL SHIELD N/C

Code CR5200 Specifications

General

Brand	Code
Model	CR5200
Category	Barcode Reader
Language	English
