CODEL Operation and Maintenance Manual
Issue : A Rev. : 3 Date : 13/11/2018 Ref. : 100351
P a g e | 6
3.2 Construction and Enclosure:
Aluminium Steel 316 (optional)
Construction:
Epoxy Coated Die-Cast Aluminium
Stainless Steel 316L or Stainless Steel
316Ti
Colour/Finish:
Black (RAL 9005 - Jet Black)
(Aluminium)
Silver/Ground, Grain 240 (S/S)
Enclosure Rating:
Designed to IP66 (IP69K Optional)
Designed to IP66
Weight:
4.5 kg
5 kg
Outline Dimension:
200 (L) x 230 (H) x 110 (D) (mm)
200 (L) x 250 (H) x 150 (D) (mm)
3.3 Output and Interface
Communication Port:
No.:
1
Type
:
RS485 MODBUS RTU (Optional)
3.4 Compliance and Certification:
EMC:
Designed to EN61326-1:2006 & EN50270:2006
Low Voltage:
73/23/EEC (as per datasheet) or 73/23/EEC - Low Voltage and 89/336/EEC -
EMC (as per manual)
Protection:
Designed to IP66
Tunnel Regulation Guidelines:
RABT 2006, RVS 09.02.22 2007
