CODEL Tunnel Tech 500 Series User Manual

CODEL Operation and Maintenance Manual
Issue : A Rev. : 3 Date : 13/11/2018 Ref. : 100351
P a g e | 8
3.7 Cables
Recommended Cable Minimum
Specification
Power Supply Cable:
Shielding: Shielded to enclosure
Cores / Wire Diameter: 2 Core / 1mm
Typically Supplied by: Customer
RS485 ModBUS Cable:
Shielding: Shielded away from enclosure
Cores / Wire Diameter: 2 Core / 0.5mm
Typically Supplied by: Customer
Analogue Output Cable:
Shielding: Shielded to enclosure
Cores / Wire Diameter: 4 Core / 1mm
Typically Supplied by:
Customer
Contact Output Cable:
Shielding: Shielded to enclosure
Cores / Wire Diameter: 4 Core / 1mm
Typically Supplied by: Customer

CODEL Tunnel Tech 500 Series Specifications

General

Brand	CODEL
Model	Tunnel Tech 500 Series
Category	Measuring Instruments
Language	English
