COEF MP 700 ZOOM - Channels and Digital Values

Pag. 10 http://www.coef.it - info@coef.it
CH
1
2
MODE1
2
MODE2
3
4
5
6
7
8
9
10
11
7.0 CHANNELS AND DIGITAL VALUES
SHUTTER / STROBE / DIMMER
0-5SHUTTER closed
6-100 DIMMER from channel14value
101-110 DIMMER 0 > 100% Automatic 6sec.
111-120 DIMMER100%>0Automatic 6sec.
121-126 DIMMER 0 > 100% slow Faster shut down
127-132 DIMMER 0 > 100% middle Faster shut down
133-138 DIMMER 0 > 100% fast Faster shut down
139-144 DIMMER 100% > 0 slow Fas
ter open
145-150 DIMMER100%>0 middle Faster open
COLOR MODE 1
0 - 5Neutral
6 - 15 Yellow
16 - 25 Blue
26 - 35 Magenta
36 - 45 Green light
46 - 55 Orange
56 - 65 Cyano
66 - 75 Pink
76 - 85 Red
86 - 95 Blu light
96 - 105 Green
106 - 115 Wood
COLOR MODE 2
0 - 5Neutral
6 - 10 Yell
ow
11 - 15 Blue
16 - 20 Magenta
21 - 25 Green light
26 - 30 Orange
31 - 35 Cyano
36 - 40 Pink
41 - 45 Red
46 - 50 Blu light
GOBOS
0 - 10 Neutral
11- 20 GOBO 1 chann.4 controls rotation
21 - 30 GOBO 2 chann.4 controls rotation
31 - 40 GOBO 3 chann.4 controls rotation
41 - 50 GOBO 4 chann.4 controls rotation
51 - 60 GOBO 5 chann.4
controls rotation
61 - 70 GOBO 6 chann.4 controls rotation
71 - 80 GOBO 7 chann.4 controls rotation
81 - 90 GOBO 8 chann.4 controls rotation
91 - 100 GOBO 9 chann.4 controls rotation
101 - 110 GOBO 1 chann.4 controls position
ROTATION GOBOS
0 - 5 STOP
6 - 255 From 0 to 540° GOBO positioning
6 - 130 CW Rotation adjustment of the GOBO
131 - 255 CWW Rotation adjustment of the GOBO
PAN MOVEMENT
PAN MOVEMENT FINE ADJUSTMENT
TILT MOVEMENT
TILT MOVEMENT FINE ADJUSTMENT
COLOR FILTER CONVERSION
0 - 79 Neutral
80 - 169 Conversion 3400°K
170 - 255 Convers
ion 5600°K
FOCUS ADJUSTMENT
0 - 255 Linear FOCUS adjustment
LINEAR ZOOM ADJUSTEMT
0 - 255 Linear ZOOM adjustment
151-156 DIMMER100%>0 fast Faster open
157-162 DIMMER0>100%>0 slow
163-168 DIMMER0>100%>0 middle
169-174 DIMMER0>100%>0 fast
175-180 Strobe lamp from 1 to 6random [reg. 0.0-0.5 sec.]
181-186 Strobe lamp from 1 to 6random [re
g. 0.6-1.5 sec.]
187-192 Strobe lamp from 1 to 6random [reg. 1.6-2.5 sec.]
193-250 STROBE Speed adjustment
251-255 SHUTTER open
116 - 125 White-Yellow
126 - 135 Yellow-Blue
136 - 145 Blue-Magenta
146 - 155 Green light-Orange
156 - 165 Orange-Cyano
166 - 175 Cyano-Pink
176 -
185 Red-Blue light
186 - 195 Blue light-Green
196 - 200 Random full-color (slow)
201 - 205 Random full-color(fast)
206 - 230 CW Rotation adjustment
231 - 255 CCW Rotation adjustment
51 - 55 Green
56 - 60 Wood
61 - 180 Positioning
181 - 185 Random fast
186 - 190 Random middle
191 - 195 Random slow
196
- 200 Random very slow
201 - 215 Random very fast
216 - 235 CW Rotation adjustment
236 - 255 CCW Rotation adjustment
111 - 120 GOBO 2 chann.4 controls position
121 - 130 GOBO 3 chann.4 controls position
131 - 140 GOBO 4 chann.4 controls position
141 - 150 GOBO 5 chann.4 controls position
151 - 160 GOBO 6 chann.4 controls position
161 - 170 GOBO 7 chann.4 controls position
171 - 180 GOBO 8 chann.4 controls position
181 - 190 GOBO 9 chann.4 controls position
191 - 198 GOBOS Random fast
199 - 205 GOBOS Random slow
206 - 230 CW Rotation adjustment
231 - 255 CWW Rotation adjustment
