8.0 LAMP ADJUSTMENT
Open thecover of MP700 Zoom by the 4 fast screw.
The gobo-wheel of the MP 700 Zoom containsdi-
chroic gobos. They are interchangeable simply by remo-
ving the littleelastic ring with a screwdriver(see figure).
Inorde
r to replace a dichroic gobo with a steelgobo,
putathickringbetween the goboand theelastic ring.
Insertthechosen goboand place again the steel
ring, paying attention that it reaches its correct position.
9.0 GOBOS REPLACEMENT
•
Don’t look directly the beam trough the lens.
•
The lamp is pre-regulated by the factory.
Only fine-adjustment. Don’t move the screws
”C” up to upper or lower extremities.
Lamp adjustment is necessary to obtain a uniformand powerful
light beam.Switch on theprojector andset thechannels without
goboand colors. Adjustthethree screws C untilyoureach the
ideal condition between power andhomogeneity.
WARNING: switch off the projector before operating
