Operation manual SR25
February 2017 Page 15
Coffed BDH | ul. Ceramiczna 28 | 64-920 Piła PL | tel+48 67 214 26 29 | www.coffed.pl
The roasting screen allows the operator to control all the functions of the SR25 coffee roasting line in order
to do the coffee roasting process. The displayed information include the status of the burner, motors, flaps
and the work mode (manual automatic). The full roasting process can be carried out using this screen only.
The displayed information:
No.
Icon
Description / function
1.
Roasting mode selection. When the slider -
Is at the side, then the machine works in manual mode,
when it is on the side, the machine works in automatic
mode
2.
Drum revolutions per minute (range 35-52)
3.
Automatic release of the coffee from the hopper into the
roaster on/off
4.
Hopper flap open/closed
5.
Destoner’s fan power
6.
Screenshot saved into the memory (a flash drive needs to be
inserted into the slot on the console)
7.
Current date and hour
8.
Current roasting mode
9.
Last roast time
10.
Chaff bin emptying mode
11.
Pneumatic green coffee loader on/off
12.
Destoner fan power controls
13.
Destoner on/off, cooling bin flap open/closed. Pulsating arrow
indicates that the destoner is starting.
14.
Cooling bin arms revolutions per minute (range 7-12)
