Operation manual SR25
February 2017 Page 19
Coffed BDH | ul. Ceramiczna 28 | 64-920 Piła PL | tel+48 67 214 26 29 | www.coffed.pl
No.
Icon
Description / function
1.
View the current recipe
2.
Edit the selected recipe
3.
Save the recipes from the PLC to the flash drive
4.
Load the recipes from the flash drive to the PLC
5.
Edit the names of the recipes
Tablel 4. List of the recipe selection screen
3.1.5.1 Current recipe preview
Pressing the opens the recipe preview screens
Pic.17 Recipe preview screen 1
