NEO + BEVERAGE MACHINE
SPECIFICATIONS
Weight: 160kg
Height: 183cm
Width: 69.8cm
Depth: 69.8cm
Temp. Range: 1ºC to 40ºC (ambient)
SERVICES REQUIRED
Electrical Supply
Supply voltage: 230V~, 50Hz, single phase fused supply
Current rating: 16A
The fused electrical supply must be terminated at a safety isolator switch, which
provides a contact separation of at least 3mm. The isolator should be located
within 1m of the beverage machine.
Water Supply
15mm dia. water mains supply, terminating at a convenient stop tap located
within 1m of the beverage machine with an appropriate water blocker mounted
between the machine and water source. The water supply should be fitted with
appropriate water blocker.
Water Pressure
Minimum: 0.1 MPa
Maximum: 0.8 MPa
A 15mm double backcheck valve, with inspection port, should be fitted prior to
the flexible hose.
