Device Distances in mm/2D min. code 10.3 mm
lens
Distances in mm/1D min. code 10.3 mm lens
DM300
,
DM302
0-75 5 MIL 0-215 7 MIL
0-210 10 MIL 0-409 13 MIL
0-374 20MIL 0-500 18 MIL
DM303
20-110 5 MIL 20-350 7 MIL
15-325 10 MIL 25-735 13 MIL
10-580 20 MIL 25-840 18 MIL
Device Distances in mm/2D min. code 16 mm lens Distances in mm/1D min. code 16 mm lens
DM300
,
DM302
59-72 2 MIL 60-125 2 MIL
55-207 4 MIL 55-270 4 MIL
49-295 8 MIL 56-400 6 MIL
DM303
35-190 5 MIL 45-400 7 MIL
30-420 10 MIL 45-495 13 MIL
25-500 20 MIL 45-540 18 MIL
Device Distances in mm/2D min. code 25 mm lens Distances in mm/1D min. code 25 mm lens
DM300
,
DM302
100-155 2 MIL 95-155 2 MIL
95-350 4 MIL 92-350 4 MIL
90-470 8 MIL 88-380 6 MIL
DM303
95-155 2 MIL 95-155 2 MIL
90-350 4 MIL 92-360 4 MIL
88-385 8 MIL 90-390 6 MIL
10
