DataMan 300 Series Imager Specifications
Specification DataMan 300 Series Imager
Image Sensor 1/1.8 inch CMOS
Image Sensor Properties
6.9 mm x 5.5 mm (H x V); 5.3 µm square pixels (DataMan 300 and 302),
4.5 µm square pixels (DataMan 303)
Image Resolution (pixels)
l DataMan 300: 800 x 600
l DataMan 302: 1280 x 1024
l DataMan 303: 1600 x 1200
Electronic Shutter Speed
l minimum exposure: 5 µs (DataMan 300 and 302), 12 µs
(DataMan 303)
l maximum exposure: 1000 µs with internal
illumination/100000 µs with external illumination
Image Acquisition at Full Resolution
l DataMan 300 and 302: up to 60 fps
l DataMan 303: up to 40 fps
Lens Type
l S-Mount 10.3 mm F:5 (with optional liquid lens) with IR
blocking filter
l S-Mount 16 mm F:9, no IR blocking filter
l C-Mount 24 mm F:6 (with liquid lens only) with IR blocking
filter
l S-Mount 25 mm M12 lens, no IR blocking filter
l C-Mount lenses (with limitations, see below)
Limitations to C-Mount lenses:
20
