Connect the Ethernet Cable
CAUTION: The Ethernet cable shield must be grounded at the far end.
Whatever this cable is plugged into (usually a switch or router) should have a
grounded Ethernet connector. A digital voltmeter should be used to validate
the grounding. If the far end device is not grounded, a ground wire should be
added in compliance with local electrical codes.
1. Connect the Ethernet cable's M12 connector to the DataMan system's
ENETconnector.
2. Connect the Ethernet cable's RJ-45 connector to a switch/router or PC, as
applicable.
Connect the Breakout Cable
CAUTION: To reduce emissions, connect the far end of the Breakout cable
shield to frame ground.
Note:
l I/O wiring or adjustments to I/O devices should be performed when
the reader is not receiving power.
l You can clip unused wires short or use a tie made of non-conductive
material to tie them back.Keep bare wires separated from the
+24VDC wire.
1. Verify that the 24VDC power supply is unplugged and not receiving power.
2. Attach the Breakout cable's +24VDC and Ground to the corresponding
terminals on the power supply.
15
