Mounting
CAUTION: It is recommended the reader be grounded, either by mounting
the reader to a fixture that is electrically grounded or by attaching a wire from
the reader’s mounting fixture to frame ground or Earth ground. If a ground
wire is used, it should be attached to one of the four mounting points on the
back plate of the reader; not to the mounting points on the front of the reader.
Mounting the DataMan reader at a slight angle (15°) can reduce reflections and
improve performance.
Use the set of mounting holes on the bottom part to mount the DataMan reader.
For more information on mounting, see the DataMan 300 Reference Manual.
