DataMan 300 Series Specifications
Weight
165 g
Operating Temperature
0ºC — 45ºC (+32ºF — 113ºF)
Storage Temperature
-10ºC — +60ºC (+14ºF — +140ºF)
Maximum Humidity < 95% (non-condensing)
Environmental
IP65 (with cable or protection cap attached to all connectors, front cover properly
installed)
LED Safety IEC62471: red illumination: Exempt Risk Group, blue and white illuminations:
Risk Group 1 (Low-Risk). No further labeling is required.
RS-232 RxD, TxD according to TIA/EIA-232-F
Codes
1-Dbarcodes: Codabar, Code 39, Code 128, and Code 93, Interleaved 2 of 5,
MSI, Pharma, GS1 DataBar, Postal, UPC/EAN/JAN
2-D codes: Data Matrix
TM
(IDMax and IDQuick: ECC 0, 50, 80, 100, 140, and
200), QR Code and microQR Code, MaxiCode, DotCode, Aztec Code, RSS/CS
Stacked codes: PDF 417, MicroPDF 417
Discrete I/O operating limits
HS Output 0,1,2,3 I
MAX
50 mA
R
MIN
@ 12 VDC 200 Ω
Input 0 (Trigger) V
IH
±12 — ±28 V
Input 1,2,3 V
IL
0 — ±8 V
I
TYP
@ 12 VDC 2.0 mA
@ 24 VDC 4.2 mA
