CAUTION: Never connect voltages other than 24VDC. Always
observe the polarity shown.
3. Attach the Breakout cable's M12 connector to the DataMan 300 reader's
24VDC connector.
4. Restore power to the 24VDC power supply and turn it on if necessary.
16
