Preparing for Your New Portable Spa
6
Coleman
®
Spas (online sales)
LTR50001135, Rev. A
Coleman logo (white)
<----------
DIP Switch De nitions for VS520 system
Note: Arrow indicates factory default setting.
OFF Position (Down) ON Position (Up)
Test Mode OFF
A1 Test mode (normally OFF)
Control amp draw requirements
-- with A10 -- see table 1 below
A2 See table 1 below
Pump 2 is 2-speed
A3 Pump 2 is 1-speed
Aux Freeze (must remain OFF)
A4
Pump 1 speeds and Circ Modes
-- with A5 -- see table 2 below
A5
See table 2 below
Single voltage heating (240VAC
only)
A6
Dual voltage heating enabled
J17/26 disabled
A7
J17/26 enabled for blower or
1-speed pump
Temperature displayed in
Fahrenheit
A8
Temperature displayed in
Celsius
Pump 1 speeds and Circ Modes
-- see table 2 below
A9
See table 2 below
Control amp draw requirements
-- with A2 -- see table 1 below
A10
See table 1 below
Table 1
Factory
default
No. of high
speed pumps
before heat
disabled A2 A10
0 OFF OFF
1 ON OFF
2 OFF ON
3 ON ON
High Power 60 Hz Con guration
Testing the GFCI Breaker
Test the GFCI breaker prior to rst use and periodically when the spa is powered. To test the GFCI breaker
follow these instructions (spa should be operating):
Press the TEST button on the GFCI. The GFCI will trip and the spa will shut off.1.
Reset the GFCI breaker by switching the breaker to the full OFF position, wait a moment, then turn the 2.
breaker back on. The spa should have power again.
Table 2
Factory
default Circ Mode
Pump 1
Speed A5 A9
Non-circ 2-speed OFF OFF
Circ “acts like
Pump 1 low”
1-speed ON OFF
24 hours with
3°F shut-off
1-speed OFF ON
24 hours with
3°F shut-off
2-speed ON ON
To Next Page
