TO IDLE WHEN RELEASED.
FREE MOVEMENT AND SNAP BACK
THROTTLE CABLE SHOULD HAVE
BEFORE STARTING ENGINE, THE
ALWAYS CHECK THROTTLE CABLE
! WARNING
SECURE WIRES AND CABLES
INSTALL CLUTCH COVER
2. Secure wires and cables to frame
using the Zip ties provided.
Zip Ties
Zip Ties
1. Make sure the On/Off Switch
wire, throttle cable and brake
cable are not kinked and have free
movement when the handle bars
are turned from left to right.
!
WARNING
8
