Coleman CT200U-EX V Assembly Instructions

OIL AND FUEL
Engine Oil
1
Fuel level
Filler neck
FUEL
Never use leaded gasoline in this product.
It could affect the engine’s emissions and
damage the engine.
Mini Bike requires clean unleaded regular
gasoline with a minimum octane rating of
86 or higher.
Fill with gasoline up to the bottom of the
ller neck.
Fill level
Mini bike is shipped without
engine oil, fill with
SAE 10W-30 Motor Oil.
Refer to owner's manual for
correct amount and grade of
engine oil.
Caution: Do not over or under ll
with engine oil
9

Coleman CT200U-EX V Specifications

General

Horsepower	6.5 hp
Weight Capacity	200 lbs
Fuel System	Carburetor
Starting System	Recoil start
Final Drive	Chain
Frame	Steel
Rear Brake	Drum
Top Speed	24 mph
Transmission	Automatic
Tires	19 x 7-8
Dry Weight	119 lbs
Engine Type	Air-cooled, 4-stroke, single-cylinder
