8-18 Periodic Maintenance and Adjustment
Tightening torque:
Final gear oil filler bolt:
16.3 ft·lbs (23 Nm, 2.3 m·kgf)
7. Check for oil leakage. If oil leakage is
found, check for the cause.
Dierential Gear O il
Checking the Dierential Gear O il Level
1. Place the vehicle on a level surface.
2. Remove the differential gear oil filler bolt
and check the oil level. It should be up to
the brim of the filler hole. If the level is
low, add sufficient oil of the
recommended type to raise it to the
specified level.
1. Speed sensor 2. Correct oil level
3. Differential gear oil
CAUTION :
1. Be sure no foreign material enters the
differential gear case.
2. Please clean the sensor every 310 miles
(500km).
