Coleman UT400 - To Change from 2 WD to 4 WD; To Change from 4 WD to 2 WD

4-13 Control Functions
To change from 2WD to 4WD
Stop the vehicle, be sure the select lever is
set to position
，and then set the switch to
“4WD”. When the vehicle is in 4WD, the 4WD
indicator will come on in the multi-function
display.
To change from 4WD to 2WD
Stop the vehicle, and then set the switch to
“2WD” 。The 4WD indicator will go out in the
multi-function display.
On -Command Dierential Gear Lock
S witch “ 2WD /LOCK ”
To lock the differential gear in 4WD, stop the
vehicle, make sure the On-Command
four-wheel-drive switch is set to “4WD”,
move the select lever to position
, and then
set the switch to “LOCK”.
1. On-Command dierential lock switch “ 4WD/LOCK”
2. Select lever
When the differential gear is locked, the
